因近期有一个项目需要上线，在评估使用什么架构时，和开发同仁沟通需求，了解到该应用为oltp但是数据量很集中，会有几张超大的表，如果要保证事务效率，使用mysql集群难免会要做分库分表，对后期的运维带来很大的挑战；而tidb属于分布式集群，tikv的行存模式非常适用于大表事务性业务，因此选型用tidb来作为该应用的底层数据库架构；
安装集群的一些基本配置要求请参考如下官方文档，这里不再赘述
https://docs.pingcap.com/zh/tidb/stable/hardware-and-software-requirements
tidb7.5lts 长期支持版本相关特性介绍如下链接
https://www.modb.pro/db/1734025930354548736
ps：默认命令为加粗斜体
二.安装前准备
本次安装为测试环境配置为1 台tidb/pd 3台tikv
配置信息 | ip | |
tidb/pd | 1台8c/16gb 200gb centos7.9 | 10.189.60.201 |
tikv | 3台8c/32gb 200gb centos7.9 | 10.189.60.202/203/204 |
- 1.需要开通外网，并配置好外部yum源 （安装依赖包，tiup，mysql等都需要外网拉取）
- 2.安装依赖包
编译和构建 tidb 所需的依赖库 | 版本 |
golang | 1.21 及以上版本 |
rust | nightly-2022-07-31 及以上版本 |
gcc | 7.x |
llvm | 13.0 及以上版本 |
ntp | none |
ntpdate | none |
sshpass | 1.06 及以上 |
numactl | 2.0.12 及以上 |
2.1 安装依赖包
yum install –y gcc llvm sshpass numactl ntp ntpdate
2.2安装go语言包1.21 及以上版本
go m6米乐安卓版下载官网下载
下载go1.21.5.linux-amd64.tar.gz
上传到集群各个主机
chown root:root go1.21.5.linux-amd64.tar.gz ##修改属性
tar -c /usr/local -xzf go1.21.5.linux-amd64.tar.gz ##解压到执行目录
vi .bash_profile ##修改root 环境变量
path=$path:$home/bin:/usr/local/go/bin
# go version ##生效环境变量后检查go版本
2.3安装rust语言包
curl --proto '=https' --tlsv1.2 https://sh.rustup.rs -ssf | sh
安装完成后确认版本
# rustc --version
3.设置临时空间
sudo mkdir /tmp/tidb
如果目录 /tmp/tidb 已经存在，需确保有写入权限。
sudo chmod -r 777 /tmp/tidb
4.关闭防火墙
检查防火墙状态（以 centos 7.x 为例）
sudo firewall-cmd --state
sudo systemctl status firewalld.service
关闭防火墙服务
sudo systemctl stop firewalld.service
关闭防火墙自动启动服务
sudo systemctl disable firewalld.service
检查防火墙状态
sudo systemctl status firewalld.service
5.配置ntp服务
yum install -y ntp ntpdate
systemctl start ntpd.service
systemctl enable ntpd.service
systemctl status ntpd.service
6.检测及关闭swap
echo "vm.swappiness = 0">> /etc/sysctl.conf
swapoff –a
sysctl –p
vi /etc/fstab
# 注释加载swap分区的那行记录
#uuid=4f863b5f-20b3-4a99-a680-ddf84a3602a4 swap swap defaults 0 0
三.检查和配置操作系统优化参数
在生产系统的 tidb 中，建议对操作系统进行如下的配置优化：
- 1.关闭透明大页（即 transparent huge pages，缩写为 thp）。数据库的内存访问模式往往是稀疏的而非连续的。当高阶内存碎片化比较严重时，分配 thp 页面会出现较高的延迟。
- 2.将存储介质的 i/o 调度器设置为 noop。对于高速 ssd 存储介质，内核的 i/o 调度操作会导致性能损失。将调度器设置为 noop 后，内核不做任何操作，直接将 i/o 请求下发给硬件，以获取更好的性能。同时，noop 调度器也有较好的普适性。
- 3.为调整 cpu 频率的 cpufreq 模块选用 performance 模式。将 cpu 频率固定在其支持的最高运行频率上，不进行动态调节，可获取最佳的性能。
因为本次使用虚拟机 且无ssd 2/3项目无需调整
3.1修改当前的内核配置立即关闭透明大页。
echo never > /sys/kernel/mm/transparent_hugepage/enabled
echo never > /sys/kernel/mm/transparent_hugepage/defrag
检查修改后的状态
cat /sys/kernel/mm/transparent_hugepage/enabled
always madvise [never]
3.2 执行以下命令修改 sysctl 参数。
echo "fs.file-max = 1000000">> /etc/sysctl.conf
echo "net.core.somaxconn = 32768">> /etc/sysctl.conf
echo "net.ipv4.tcp_tw_recycle = 0">> /etc/sysctl.conf
echo "net.ipv4.tcp_syncookies = 0">> /etc/sysctl.conf
echo "vm.overcommit_memory = 1">> /etc/sysctl.conf
sysctl -p
3.3 执行以下命令配置用户的 limits.conf 文件。
cat << eof >>/etc/security/limits.conf
tidb soft nofile 1000000
tidb hard nofile 1000000
tidb soft stack 32768
tidb hard stack 32768
eof
四.手动配置 ssh 互信及 sudo 免密码
对于有需求，通过手动配置中控机至目标节点互信的场景，可参考本段。通常推荐使用 tiup 部署工具会自动配置 ssh 互信及免密登录，可忽略本段内容
配置互信和oracle 11g rac配置互信类似
以 root 用户依次登录到部署目标机器创建 tidb 用户并设置登录密码。
useradd tidb && \
passwd tidb
置好 sudo 免密码。
visudo
tidb all=(all) nopasswd: all
配置互信
ssh-keygen -t rsa
ssh-copy-id -i ~/.ssh/id_rsa.pub 10.189.60.201(ip)
因为本次配置tidb和pd在同一台所以也需要配置本机互信
注意：因为修改了默认的ssh端口 ssh时候需要使用
ssh –p xxxx ip/hostname
为了不加-p的参数需要修改
vi /etc/ssh/ssh_config
拿掉port的注释 并修改为修改后的端口号即可
确认互信成功
[tidb@yzptltidb01t ~]$ ssh-copy-id -i ~/.ssh/id_rsa.pub 10.189.60.204/bin/ssh-copy-id: info: source of key(s) to be installed: "/home/tidb/.ssh/id_rsa.pub"the authenticity of host '[10.189.60.204]:11122 ([10.189.60.204]:11122)' can't be established.ecdsa key fingerprint is sha256:bq5xo2 g76dkfqsjx heznuwutknsfukyy6wrwu3lyc.ecdsa key fingerprint is md5:5f:dc:02:69:20:92:cf:4d:56:26:f0:5c:bd:f5:56:ee.are you sure you want to continue connecting (yes/no)? yes/bin/ssh-copy-id: info: attempting to log in with the new key(s), to filter out any that are already installed/bin/ssh-copy-id: info: 1 key(s) remain to be installed -- if you are prompted now it is to install the new keystidb@10.189.60.204's password: number of key(s) added: 1now try logging into the machine, with: "ssh '10.189.60.204'"and check to make sure that only the key(s) you wanted were added.[tidb@yzptltidb01t ~]$ ssh 10.189.60.204 ##直接登录到目标主机[tidb@yzptltikv03t ~]$五.搭建集群服务
tiup 是 tidb 4.0 版本引入的集群运维工具，tiup cluster 是 tiup 提供的使用 golang 编写的集群管理组件，通过 tiup cluster 组件就可以进行日常的运维工作，包括部署、启动、关闭、销毁、弹性扩缩容、升级 tidb 集群，以及管理 tidb 集群参数。
目前 tiup 可以支持部署 tidb、tiflash、tidb binlog、ticdc 以及监控系统。
本文将介绍 tidb 集群拓扑的具体部署步骤。
5.1下载并安装tiup
在中控机上下载安装tiup，本次测试集群就是tidb/pd主机
curl --proto '=https' --tlsv1.2 -ssf https://tiup-mirrors.pingcap.com/install.sh | sh
[root@yzptltidb01t ~]# source /root/.bash_profile ##重新声明环境变量
[root@yzptltidb01t ~]# tiup cluster ##安装tiup cluster组件
tiup is checking updates for component cluster ...timeout(2s)!
the component `cluster` version is not installed; downloading from repository.
download https://tiup-mirrors.pingcap.com/cluster-v1.14.0-linux-amd64.tar.gz 8.75 mib / 8.75 mib 100.00% 38.12 mib/s ##提示少个包 后面下了安装一下，我看也有别的博主未下载也可以使用
starting component `cluster`: /root/.tiup/components/cluster/v1.14.0/tiup-cluster
deploy a tidb cluster for production
usage:
tiup cluster [command]
available commands:
check perform preflight checks for the cluster.
deploy deploy a cluster for production
start start a tidb cluster
stop stop a tidb cluster
restart restart a tidb cluster
scale-in scale in a tidb cluster
scale-out scale out a tidb cluster
destroy destroy a specified cluster
clean (experimental) cleanup a specified cluster
upgrade upgrade a specified tidb cluster
display display information of a tidb cluster
prune destroy and remove instances that is in tombstone state
list list all clusters
audit show audit log of cluster operation
import import an exist tidb cluster from tidb-ansible
edit-config edit tidb cluster config
show-config show tidb cluster config
reload reload a tidb cluster's config and restart if needed
patch replace the remote package with a specified package and restart the service
rename rename the cluster
enable enable a tidb cluster automatically at boot
disable disable automatic enabling of tidb clusters at boot
replay replay previous operation and skip successed steps
template print topology template
tls enable/disable tls between tidb components
meta backup/restore meta information
rotatessh rotate ssh keys on all nodes
help help about any command
completion generate the autocompletion script for the specified shell
flags:
-c, --concurrency int max number of parallel tasks allowed (default 5)
--format string (experimental) the format of output, available values are [default, json] (default "default")
-h, --help help for tiup
--ssh string (experimental) the executor type: 'builtin', 'system', 'none'.
--ssh-timeout uint timeout in seconds to connect host via ssh, ignored for operations that don't need an ssh connection. (default 5)
-v, --version version for tiup
--wait-timeout uint timeout in seconds to wait for an operation to complete, ignored for operations that don't fit. (default 120)
-y, --yes skip all confirmations and assumes 'yes'
use "tiup cluster help [command]" for more information about a command.
[root@yzptltidb01t ~]# wget ##下载这个包
--2023-12-18 16:41:12-- https://tiup-mirrors.pingcap.com/cluster-v1.14.0-linux-amd64.tar.gz
resolving tiup-mirrors.pingcap.com (tiup-mirrors.pingcap.com)... 120.240.109.47, 120.241.84.45, 111.48.217.20
connecting to tiup-mirrors.pingcap.com (tiup-mirrors.pingcap.com)|120.240.109.47|:443... connected.
http request sent, awaiting response... 200 ok
length: 9178241 (8.8m) [application/x-compressed]
saving to: ‘cluster-v1.14.0-linux-amd64.tar.gz’
100%[======================================================================================================================>] 9,178,241 16.2mb/s in 0.5s
2023-12-18 16:41:13 (16.2 mb/s) - ‘cluster-v1.14.0-linux-amd64.tar.gz’ saved [9178241/9178241]
[root@yzptltidb01t ~]# tar -xzf cluster-v1.14.0-linux-amd64.tar.gz
[root@yzptltidb01t ~]#
5.2更新tiup
[root@yzptltidb01t ~]# tiup update --self && tiup update cluster
download https://tiup-mirrors.pingcap.com/tiup-v1.14.0-linux-amd64.tar.gz 4.83 mib / 4.83 mib 100.00% 26.31 mib/s
updated successfully!
component cluster version v1.14.0 is already installed
updated successfully!
[root@yzptltidb01t ~]#
[root@yzptltidb01t ~]# tiup --binary cluster ---更新后的版本
/root/.tiup/components/cluster/v1.14.0/tiup-cluster
5.3配置参数文件
[root@yzptltidb01t ~]# cat topo.yaml
# # global variables are applied to all deployments and used as the default value of
# # the deployments if a specific deployment value is missing.
global:
user: "tidb"
ssh_port: 11122
deploy_dir: "/tidb-deploy"
data_dir: "/tidb-data"
pd_servers:
- host: 10.189.60.201
tidb_servers:
- host: 10.189.60.201
tikv_servers:
- host: 10.189.60.202
- host: 10.189.60.203
- host: 10.189.60.204
monitoring_servers:
- host: 10.189.60.201
grafana_servers:
- host: 10.189.60.201
alertmanager_servers:
- host: 10.189.60.201
5.4安装前预检查
tiup cluster check ./topo.yaml --user root –p
[root@yzptltidb01t ~]# tiup cluster check ./topo.yaml --user root –p
tiup is checking updates for component cluster ...
starting component `cluster`: /root/.tiup/components/cluster/v1.14.0/tiup-cluster check ./topo.yaml --user root –p
input ssh password:
detect cpu arch name
- detecting node 10.189.60.201 arch info ... done
- detecting node 10.189.60.202 arch info ... done
- detecting node 10.189.60.203 arch info ... done
- detecting node 10.189.60.204 arch info ... done
detect cpu os name
- detecting node 10.189.60.201 os info ... done
- detecting node 10.189.60.202 os info ... done
- detecting node 10.189.60.203 os info ... done
- detecting node 10.189.60.204 os info ... done
download necessary tools
- downloading check tools for linux/amd64 ... done
collect basic system information
collect basic system information
- getting system info of 10.189.60.201:11122 ... ⠴ copycomponent: component=insight, version=, remote=10.189.60.201:/tmp/tiup os=linux, arch=amd64
collect basic system information
collect basic system information
- getting system info of 10.189.60.201:11122 ... done
- getting system info of 10.189.60.202:11122 ... done
- getting system info of 10.189.60.203:11122 ... done
- getting system info of 10.189.60.204:11122 ... done
check time zone
- checking node 10.189.60.201 ... done
- checking node 10.189.60.202 ... done
- checking node 10.189.60.203 ... done
- checking node 10.189.60.204 ... done
check system requirements
- checking node 10.189.60.201 ... ⠴ checksys: host=10.189.60.201 type=exist
check system requirements
- checking node 10.189.60.201 ... done
check system requirements
- checking node 10.189.60.201 ... done
check system requirements
- checking node 10.189.60.201 ... done
check system requirements
check system requirements
check system requirements
- checking node 10.189.60.201 ... done
check system requirements
- checking node 10.189.60.201 ... done
- checking node 10.189.60.202 ... done
- checking node 10.189.60.203 ... done
- checking node 10.189.60.204 ... done
- checking node 10.189.60.201 ... done
- checking node 10.189.60.201 ... done
- checking node 10.189.60.201 ... done
- checking node 10.189.60.201 ... done
- checking node 10.189.60.201 ... done
- checking node 10.189.60.202 ... done
- checking node 10.189.60.203 ... done
- checking node 10.189.60.204 ... done
cleanup check files
- cleanup check files on 10.189.60.201:11122 ... done
- cleanup check files on 10.189.60.202:11122 ... done
- cleanup check files on 10.189.60.203:11122 ... done
- cleanup check files on 10.189.60.204:11122 ... done
node check result message
---- ----- ------ -------
10.189.60.202 timezone pass time zone is the same as the first pd machine: asia/shanghai
10.189.60.202 cpu-governor warn unable to determine current cpu frequency governor policy
10.189.60.202 swap warn swap is enabled, please disable it for best performance
10.189.60.202 memory pass memory size is 32768mb
10.189.60.202 thp pass thp is disabled
10.189.60.202 command pass numactl: policy: default
10.189.60.202 os-version pass os is centos linux 7 (core) 7.9.2009
10.189.60.202 cpu-cores pass number of cpu cores / threads: 8
10.189.60.202 network pass network speed of ens192 is 10000mb
10.189.60.202 disk warn mount point / does not have 'noatime' option set
10.189.60.202 selinux pass selinux is disabled
10.189.60.203 swap warn swap is enabled, please disable it for best performance
10.189.60.203 memory pass memory size is 32768mb
10.189.60.203 disk warn mount point / does not have 'noatime' option set
10.189.60.203 command pass numactl: policy: default
10.189.60.203 timezone pass time zone is the same as the first pd machine: asia/shanghai
10.189.60.203 os-version pass os is centos linux 7 (core) 7.9.2009
10.189.60.203 network pass network speed of ens192 is 10000mb
10.189.60.203 selinux pass selinux is disabled
10.189.60.203 thp pass thp is disabled
10.189.60.203 cpu-cores pass number of cpu cores / threads: 8
10.189.60.203 cpu-governor warn unable to determine current cpu frequency governor policy
10.189.60.204 selinux pass selinux is disabled
10.189.60.204 cpu-cores pass number of cpu cores / threads: 8
10.189.60.204 swap warn swap is enabled, please disable it for best performance
10.189.60.204 network pass network speed of ens192 is 10000mb
10.189.60.204 disk warn mount point / does not have 'noatime' option set
10.189.60.204 thp pass thp is disabled
10.189.60.204 command pass numactl: policy: default
10.189.60.204 timezone pass time zone is the same as the first pd machine: asia/shanghai
10.189.60.204 os-version pass os is centos linux 7 (core) 7.9.2009
10.189.60.204 cpu-governor warn unable to determine current cpu frequency governor policy
10.189.60.204 memory pass memory size is 32768mb
10.189.60.201 os-version pass os is centos linux 7 (core) 7.9.2009
10.189.60.201 cpu-governor warn unable to determine current cpu frequency governor policy
10.189.60.201 swap warn swap is enabled, please disable it for best performance
10.189.60.201 memory pass memory size is 16384mb
10.189.60.201 sysctl fail vm.swappiness = 60, should be 0
10.189.60.201 command fail numactl not usable, bash: numactl:
##未禁用swap，未安装numactl
command not found
10.189.60.201 cpu-cores pass number of cpu cores / threads: 8
10.189.60.201 network pass network speed of ens192 is 10000mb
10.189.60.201 disk warn mount point / does not have 'noatime' option set
10.189.60.201 selinux pass selinux is disabled
10.189.60.201 thp pass thp is disabled
transaction summary
处理完成后 再次check 确保没有fail
5.5安装tidb
[root@yzptltidb01t ~]# tiup list tidb ##list出可以安装的版本
v6.1.2 2022-10-24t15:16:17 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v6.1.3 2022-12-05t11:50:23 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v6.1.4 2023-02-08t11:34:10 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v6.1.5 2023-02-28t11:23:57 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v6.1.6 2023-04-12t11:05:35 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v6.1.7 2023-07-12t11:22:57 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v6.2.0 2022-08-23t09:14:36 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v6.3.0 2022-09-30t10:59:36 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v6.4.0 2022-11-17t11:26:23 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v6.5.0 2022-12-29t11:32:06 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v6.5.1 2023-03-10t13:36:50 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v6.5.2 2023-04-21t10:52:46 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v6.5.3 2023-06-14t14:36:43 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v6.5.4 2023-08-28t11:40:24 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v6.5.5 2023-09-21t11:51:14 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v6.5.6 2023-12-07t07:12:10z darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v6.6.0 2023-02-20t16:43:16 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v7.0.0 2023-03-30t10:33:19 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v7.1.0 2023-05-31t14:49:49 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v7.1.1 2023-07-24t11:39:38 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v7.1.2 2023-10-25t03:58:13z darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v7.2.0 2023-06-29t11:57:48 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v7.3.0 2023-08-14t12:41:31 08:00 darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v7.4.0 2023-10-12t04:07:12z darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v7.5.0 2023-12-01t03:55:55z darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
v7.6.0-alpha-nightly-20231216 2023-12-16t15:17:07z darwin/amd64,darwin/arm64,linux/amd64,linux/arm64
正式安装tidb
#本次安装选择tidb 7.5 改版本为7.x第二个lts长期支持版本
tiup cluster deploy test-tidb v7.5.0 ./topo.yaml --user root –p
##test-tidb 为当前安装集群的名
[root@yzptltidb01t ~]# tiup cluster deploy test-tidb v7.5.0 ./topo.yaml --user root -p
tiup is checking updates for component cluster ...
starting component `cluster`: /root/.tiup/components/cluster/v1.14.0/tiup-cluster deploy test-tidb v7.5.0 ./topology.yaml --user root -p
input ssh password:
detect cpu arch name
- detecting node 10.189.60.201 arch info ... done
- detecting node 10.189.60.202 arch info ... done
- detecting node 10.189.60.203 arch info ... done
- detecting node 10.189.60.204 arch info ... done
detect cpu os name
- detecting node 10.189.60.201 os info ... done
- detecting node 10.189.60.202 os info ... done
- detecting node 10.189.60.203 os info ... done
- detecting node 10.189.60.204 os info ... done
please confirm your topology:
cluster type: tidb
cluster name: test-tidb
cluster version: v7.5.0
role host ports os/arch directories
---- ---- ----- ------- -----------
pd 10.189.60.201 2379/2380 linux/x86_64 /tidb-deploy/pd-2379,/tidb-data/pd-2379
tikv 10.189.60.202 20160/20180 linux/x86_64 /tidb-deploy/tikv-20160,/tidb-data/tikv-20160
tikv 10.189.60.203 20160/20180 linux/x86_64 /tidb-deploy/tikv-20160,/tidb-data/tikv-20160
tikv 10.189.60.204 20160/20180 linux/x86_64 /tidb-deploy/tikv-20160,/tidb-data/tikv-20160
tidb 10.189.60.201 4000/10080 linux/x86_64 /tidb-deploy/tidb-4000
prometheus 10.189.60.201 9090/12020 linux/x86_64 /tidb-deploy/prometheus-9090,/tidb-data/prometheus-9090
grafana 10.189.60.201 3000 linux/x86_64 /tidb-deploy/grafana-3000
alertmanager 10.189.60.201 9093/9094 linux/x86_64 /tidb-deploy/alertmanager-9093,/tidb-data/alertmanager-9093
attention:
1. if the topology is not what you expected, check your yaml file.
2. please confirm there is no port/directory conflicts in same host.
do you want to continue? [y/n]: (default=n) y
generate ssh keys ... done
download tidb components
- download pd:v7.5.0 (linux/amd64) ... done
- download tikv:v7.5.0 (linux/amd64) ... done
- download tidb:v7.5.0 (linux/amd64) ... done
- download prometheus:v7.5.0 (linux/amd64) ... done
- download grafana:v7.5.0 (linux/amd64) ... done
- download alertmanager: (linux/amd64) ... done
- download node_exporter: (linux/amd64) ... done
- download blackbox_exporter: (linux/amd64) ... done
initialize target host environments
- prepare 10.189.60.203:11122 ... done
- prepare 10.189.60.204:11122 ... done
- prepare 10.189.60.201:11122 ... done
- prepare 10.189.60.202:11122 ... done
deploy tidb instance
- copy pd -> 10.189.60.201 ... done
- copy tikv -> 10.189.60.202 ... done
- copy tikv -> 10.189.60.203 ... done
- copy tikv -> 10.189.60.204 ... done
- copy tidb -> 10.189.60.201 ... done
- copy prometheus -> 10.189.60.201 ... done
- copy grafana -> 10.189.60.201 ... done
- copy alertmanager -> 10.189.60.201 ... done
- deploy node_exporter -> 10.189.60.201 ... done
- deploy node_exporter -> 10.189.60.202 ... done
- deploy node_exporter -> 10.189.60.203 ... done
- deploy node_exporter -> 10.189.60.204 ... done
- deploy blackbox_exporter -> 10.189.60.202 ... done
- deploy blackbox_exporter -> 10.189.60.203 ... done
- deploy blackbox_exporter -> 10.189.60.204 ... done
- deploy blackbox_exporter -> 10.189.60.201 ... done
copy certificate to remote host
init instance configs
- generate config pd -> 10.189.60.201:2379 ... done
- generate config tikv -> 10.189.60.202:20160 ... done
- generate config tikv -> 10.189.60.203:20160 ... done
- generate config tikv -> 10.189.60.204:20160 ... done
- generate config tidb -> 10.189.60.201:4000 ... done
- generate config prometheus -> 10.189.60.201:9090 ... done
- generate config grafana -> 10.189.60.201:3000 ... done
- generate config alertmanager -> 10.189.60.201:9093 ... done
init monitor configs
- generate config node_exporter -> 10.189.60.204 ... done
- generate config node_exporter -> 10.189.60.201 ... done
- generate config node_exporter -> 10.189.60.202 ... done
- generate config node_exporter -> 10.189.60.203 ... done
- generate config blackbox_exporter -> 10.189.60.203 ... done
- generate config blackbox_exporter -> 10.189.60.204 ... done
- generate config blackbox_exporter -> 10.189.60.201 ... done
- generate config blackbox_exporter -> 10.189.60.202 ... done
enabling component pd
enabling instance 10.189.60.201:2379
enable instance 10.189.60.201:2379 success
enabling component tikv
enabling instance 10.189.60.204:20160
enabling instance 10.189.60.202:20160
enabling instance 10.189.60.203:20160
enable instance 10.189.60.202:20160 success
enable instance 10.189.60.204:20160 success
enable instance 10.189.60.203:20160 success
enabling component tidb
enabling instance 10.189.60.201:4000
enable instance 10.189.60.201:4000 success
enabling component prometheus
enabling instance 10.189.60.201:9090
enable instance 10.189.60.201:9090 success
enabling component grafana
enabling instance 10.189.60.201:3000
enable instance 10.189.60.201:3000 success
enabling component alertmanager
enabling instance 10.189.60.201:9093
enable instance 10.189.60.201:9093 success
enabling component node_exporter
enabling instance 10.189.60.204
enabling instance 10.189.60.202
enabling instance 10.189.60.201
enabling instance 10.189.60.203
enable 10.189.60.204 success
enable 10.189.60.203 success
enable 10.189.60.201 success
enable 10.189.60.202 success
enabling component blackbox_exporter
enabling instance 10.189.60.204
enabling instance 10.189.60.202
enabling instance 10.189.60.201
enabling instance 10.189.60.203
enable 10.189.60.204 success
enable 10.189.60.203 success
enable 10.189.60.201 success
enable 10.189.60.202 success
cluster `test-tidb` deployed successfully, you can start it with command: `tiup cluster start test-tidb --init`
安装成功
[root@yzptltidb01t ~]# tiup cluster list
tiup is checking updates for component cluster ...
starting component `cluster`: /root/.tiup/components/cluster/v1.14.0/tiup-cluster list
name user version path privatekey
---- ---- ------- ---- ----------
test-tidb tidb v7.5.0 /root/.tiup/storage/cluster/clusters/test-tidb /root/.tiup/storage/cluster/clusters/test-tidb/ssh/id_rsa
查看当前安装集群状态
[root@yzptltidb01t ~]# tiup cluster display test-tidb
tiup is checking updates for component cluster ...
starting component `cluster`: /root/.tiup/components/cluster/v1.14.0/tiup-cluster display test-tidb
cluster type: tidb
cluster name: test-tidb
cluster version: v7.5.0
deploy user: tidb
ssh type: builtin
grafana url: http://10.189.60.201:3000
id role host ports os/arch status data dir deploy dir
-- ---- ---- ----- ------- ------ -------- ----------
10.189.60.201:9093 alertmanager 10.189.60.201 9093/9094 linux/x86_64 down /tidb-data/alertmanager-9093 /tidb-deploy/alertmanager-9093
10.189.60.201:3000 grafana 10.189.60.201 3000 linux/x86_64 down - /tidb-deploy/grafana-3000
10.189.60.201:2379 pd 10.189.60.201 2379/2380 linux/x86_64 down /tidb-data/pd-2379 /tidb-deploy/pd-2379
10.189.60.201:9090 prometheus 10.189.60.201 9090/12020 linux/x86_64 down /tidb-data/prometheus-9090 /tidb-deploy/prometheus-9090
10.189.60.201:4000 tidb 10.189.60.201 4000/10080 linux/x86_64 down - /tidb-deploy/tidb-4000
10.189.60.202:20160 tikv 10.189.60.202 20160/20180 linux/x86_64 n/a /tidb-data/tikv-20160 /tidb-deploy/tikv-20160
10.189.60.203:20160 tikv 10.189.60.203 20160/20180 linux/x86_64 n/a /tidb-data/tikv-20160 /tidb-deploy/tikv-20160
10.189.60.204:20160 tikv 10.189.60.204 20160/20180 linux/x86_64 n/a /tidb-data/tikv-20160 /tidb-deploy/tikv-20160
total nodes: 8
可以看到当前集群的状态都是down的
5.6初始化并启动集群
[root@yzptltidb01t ~]# tiup cluster start test-tidb --init
tiup is checking updates for component cluster ...
starting component `cluster`: /root/.tiup/components/cluster/v1.14.0/tiup-cluster start test-tidb --init
starting cluster test-tidb...
[ serial ] - sshkeyset: privatekey=/root/.tiup/storage/cluster/clusters/test-tidb/ssh/id_rsa, publickey=/root/.tiup/storage/cluster/clusters/test-tidb/ssh/id_rsa.pub
[parallel] - userssh: user=tidb, host=10.189.60.201
[parallel] - userssh: user=tidb, host=10.189.60.202
[parallel] - userssh: user=tidb, host=10.189.60.201
[parallel] - userssh: user=tidb, host=10.189.60.204
[parallel] - userssh: user=tidb, host=10.189.60.201
[parallel] - userssh: user=tidb, host=10.189.60.201
[parallel] - userssh: user=tidb, host=10.189.60.203
[parallel] - userssh: user=tidb, host=10.189.60.201
[ serial ] - startcluster
starting component pd
starting instance 10.189.60.201:2379
start instance 10.189.60.201:2379 success
starting component tikv
starting instance 10.189.60.204:20160
starting instance 10.189.60.202:20160
starting instance 10.189.60.203:20160
start instance 10.189.60.204:20160 success
start instance 10.189.60.202:20160 success
start instance 10.189.60.203:20160 success
starting component tidb
starting instance 10.189.60.201:4000
start instance 10.189.60.201:4000 success
starting component prometheus
starting instance 10.189.60.201:9090
start instance 10.189.60.201:9090 success
starting component grafana
starting instance 10.189.60.201:3000
start instance 10.189.60.201:3000 success
starting component alertmanager
starting instance 10.189.60.201:9093
start instance 10.189.60.201:9093 success
starting component node_exporter
starting instance 10.189.60.204
starting instance 10.189.60.201
starting instance 10.189.60.202
starting instance 10.189.60.203
start 10.189.60.204 success
start 10.189.60.203 success
start 10.189.60.202 success
start 10.189.60.201 success
starting component blackbox_exporter
starting instance 10.189.60.204
starting instance 10.189.60.202
starting instance 10.189.60.203
starting instance 10.189.60.201
start 10.189.60.202 success
start 10.189.60.203 success
start 10.189.60.201 success
start 10.189.60.204 success
[ serial ] - updatetopology: cluster=test-tidb
started cluster `test-tidb` successfully
the root password of tidb database has been changed.
the new password is: 'n_mz@vp^17tg6e 504'.
copy and record it to somewhere safe, it is only displayed once, and will not be stored.
the generated password can not be get and shown again.
[root@yzptltidb01t ~]#
记住初始化时给的密码（和mysql类似）
5.7查看集群的状态
tiup cluster display test-tidb
这时可以看到集群的状态已经都是up了
六.启动、关闭集群命令
启动集群
tiup cluster start test-tidb
关闭集群
tiup cluster stop test-tidb
停止组件
例如，下列命令只停止 tidb 组件：
tiup cluster stop test-tidb -r tidb
停止组件中的某一个节点(如tikv)
tiup cluster stop test-tidb -n 10.189.60.202:20160
停掉后集群状态
启动组件中的某一个节点（tikv）
tiup cluster start test-tidb -n 10.189.60.202:20160
更改组件的配置后，重启组件
tiup cluster reload ${cluster-name} -r 组件名，
比如
tiup cluster reload test-tidb -r t
七. 命令行连接到 tidb 集群
tidb 兼容 mysql 协议，故需要 mysql 客户端连接，则需安装mysql 客户端。
linux7 版本的系统默认自带安装了 mariadb，需要先清理。
删除自带的mariadb
[root@yzptltidb01t ~]# rpm -qa |grep mariadb
mariadb-libs-5.5.68-1.el7.x86_64
[root@yzptltidb01t ~]#
[root@yzptltidb01t ~]# rpm -e --nodeps mariadb-libs-5.5.68-1.el7.x86_64
[root@yzptltidb01t ~]# rpm -qa |grep mariadb
安装mysql客户端
#yum -y install http://dev.mysql.com/get/mysql80-community-release-el7-10.noarch.rpm
# rpm --import https://repo.mysql.com/rpm-gpg-key-mysql-2023
# yum -y install mysql
[root@yzptltidb01t ~]# yum -y install http://dev.mysql.com/get/mysql80-community-release-el7-10.noarch.rpm
loaded plugins: fastestmirror
mysql80-community-release-el7-10.noarch.rpm | 14 kb 00:00:00
examining /var/tmp/yum-root-26cqau/mysql80-community-release-el7-10.noarch.rpm: mysql80-community-release-el7-11.noarch
marking /var/tmp/yum-root-26cqau/mysql80-community-release-el7-10.noarch.rpm to be installed
resolving dependencies
--> running transaction check
---> package mysql80-community-release.noarch 0:el7-11 will be installed
--> finished dependency resolution
dependencies resolved
================================================================================================================================================================
package arch version repository size
================================================================================================================================================================
installing:
mysql80-community-release noarch el7-11 /mysql80-community-release-el7-10.noarch 17 k
transaction summary
================================================================================================================================================================
install 1 package
total size: 17 k
installed size: 17 k
downloading packages:
running transaction check
running transaction test
transaction test succeeded
running transaction
warning: rpmdb altered outside of yum.
** found 2 pre-existing rpmdb problem(s), 'yum check' output follows:
2:postfix-2.10.1-9.el7.x86_64 has missing requires of libmysqlclient.so.18()(64bit)
2:postfix-2.10.1-9.el7.x86_64 has missing requires of libmysqlclient.so.18(libmysqlclient_18)(64bit)
installing : mysql80-community-release-el7-11.noarch 1/1
verifying : mysql80-community-release-el7-11.noarch 1/1
installed:
mysql80-community-release.noarch 0:el7-11
complete!
[root@yzptltidb01t ~]# rpm --import https://repo.mysql.com/rpm-gpg-key-mysql-2023
[root@yzptltidb01t ~]# yum -y install mysql
loaded plugins: fastestmirror
loading mirror speeds from cached hostfile
* base: mirrors.bfsu.edu.cn
* extras: mirrors.bfsu.edu.cn
* updates: mirrors.bfsu.edu.cn
base | 3.6 kb 00:00:00
not using downloaded base/repomd.xml because it is older than what we have:
current : mon mar 20 23:22:29 2023
downloaded: fri oct 30 04:03:00 2020
extras | 2.9 kb 00:00:00
mysql-connectors-community | 2.6 kb 00:00:00
mysql-tools-community | 2.6 kb 00:00:00
mysql80-community | 2.6 kb 00:00:00
updates | 2.9 kb 00:00:00
(1/3): mysql-tools-community/x86_64/primary_db | 95 kb 00:00:00
(2/3): mysql-connectors-community/x86_64/primary_db | 102 kb 00:00:00
(3/3): mysql80-community/x86_64/primary_db | 266 kb 00:00:00
resolving dependencies
--> running transaction check
---> package mysql-community-client.x86_64 0:8.0.35-1.el7 will be installed
--> processing dependency: mysql-community-client-plugins = 8.0.35-1.el7 for package: mysql-community-client-8.0.35-1.el7.x86_64
--> processing dependency: mysql-community-libs(x86-64) >= 8.0.11 for package: mysql-community-client-8.0.35-1.el7.x86_64
--> running transaction check
---> package mysql-community-client-plugins.x86_64 0:8.0.35-1.el7 will be installed
---> package mysql-community-libs.x86_64 0:8.0.35-1.el7 will be installed
--> processing dependency: mysql-community-common(x86-64) >= 8.0.11 for package: mysql-community-libs-8.0.35-1.el7.x86_64
--> running transaction check
---> package mysql-community-common.x86_64 0:8.0.35-1.el7 will be installed
--> finished dependency resolution
dependencies resolved
================================================================================================================================================================
package arch version repository size
================================================================================================================================================================
installing:
mysql-community-client x86_64 8.0.35-1.el7 mysql80-community 16 m
installing for dependencies:
mysql-community-client-plugins x86_64 8.0.35-1.el7 mysql80-community 3.5 m
mysql-community-common x86_64 8.0.35-1.el7 mysql80-community 665 k
mysql-community-libs x86_64 8.0.35-1.el7 mysql80-community 1.5 m
transaction summary
================================================================================================================================================================
install 1 package ( 3 dependent packages)
total download size: 22 m
installed size: 116 m
downloading packages:
warning: /var/cache/yum/x86_64/7/mysql80-community/packages/mysql-community-client-plugins-8.0.35-1.el7.x86_64.rpm: header v4 rsa/sha256 signature, key id 3a79bd29: nokey
public key for mysql-community-client-plugins-8.0.35-1.el7.x86_64.rpm is not installed
(1/4): mysql-community-client-plugins-8.0.35-1.el7.x86_64.rpm | 3.5 mb 00:00:00
(2/4): mysql-community-common-8.0.35-1.el7.x86_64.rpm | 665 kb 00:00:00
(3/4): mysql-community-client-8.0.35-1.el7.x86_64.rpm | 16 mb 00:00:01
(4/4): mysql-community-libs-8.0.35-1.el7.x86_64.rpm | 1.5 mb 00:00:00
----------------------------------------------------------------------------------------------------------------------------------------------------------------
total 13 mb/s | 22 mb 00:00:01
retrieving key from file:///etc/pki/rpm-gpg/rpm-gpg-key-mysql-2023
retrieving key from file:///etc/pki/rpm-gpg/rpm-gpg-key-mysql-2022
importing gpg key 0x3a79bd29:
userid : "mysql release engineering
fingerprint: 859b e8d7 c586 f538 430b 19c2 467b 942d 3a79 bd29
package : mysql80-community-release-el7-11.noarch (@/mysql80-community-release-el7-10.noarch)
from : /etc/pki/rpm-gpg/rpm-gpg-key-mysql-2022
retrieving key from file:///etc/pki/rpm-gpg/rpm-gpg-key-mysql
importing gpg key 0x5072e1f5:
userid : "mysql release engineering
fingerprint: a4a9 4068 76fc bd3c 4567 70c8 8c71 8d3b 5072 e1f5
package : mysql80-community-release-el7-11.noarch (@/mysql80-community-release-el7-10.noarch)
from : /etc/pki/rpm-gpg/rpm-gpg-key-mysql
running transaction check
running transaction test
transaction test succeeded
running transaction
installing : mysql-community-client-plugins-8.0.35-1.el7.x86_64 1/4
installing : mysql-community-common-8.0.35-1.el7.x86_64 2/4
installing : mysql-community-libs-8.0.35-1.el7.x86_64 3/4
installing : mysql-community-client-8.0.35-1.el7.x86_64 4/4
verifying : mysql-community-client-plugins-8.0.35-1.el7.x86_64 1/4
verifying : mysql-community-libs-8.0.35-1.el7.x86_64 2/4
verifying : mysql-community-client-8.0.35-1.el7.x86_64 3/4
verifying : mysql-community-common-8.0.35-1.el7.x86_64 4/4
installed:
mysql-community-client.x86_64 0:8.0.35-1.el7
dependency installed:
mysql-community-client-plugins.x86_64 0:8.0.35-1.el7 mysql-community-common.x86_64 0:8.0.35-1.el7 mysql-community-libs.x86_64 0:8.0.35-1.el7
complete!
[root@yzptltidb01t ~]#
连接数据库 并修改初始root密码
mysql -h 10.189.60.201 -p 4000 -uroot –p
[root@yzptltidb01t ~]# mysql -h 10.189.60.201 -p 4000 -uroot -p
enter password:
welcome to the mysql monitor. commands end with ; or \g.
your mysql connection id is 1543503878
server version: 8.0.11-tidb-v7.5.0 tidb server (apache license 2.0) community edition, mysql 8.0 compatible
米乐app官网下载 copyright (c) 2000, 2023, oracle and/or its affiliates.
oracle is a registered trademark of oracle corporation and/or its
affiliates. other names may be trademarks of their respective
owners.
type 'help;' or '\h' for help. type '\c' to clear the current input statement.
mysql>
mysql> show databases;
--------------------
| database |
--------------------
| information_schema |
| metrics_schema |
| performance_schema |
| mysql |
| test |
--------------------
5 rows in set (0.00 sec)
mysql> use mysql
reading table information for completion of table and column names
you can turn off this feature to get a quicker startup with -a
database changed
mysql> alter user 'root'@'%' identified by 'tidb';
query ok, 0 rows affected (0.03 sec)
八.集群监控
集群状态中有监控的url
集群的dashboard 监控整个集群的状态 密码为修改后的mysql的root密码
可以看到整个集群的整体状态
grafana 默认密码为admin/admin
首次登陆需要修改密码
首次使用需要建个新的dashboard
